Plenum Rated cable use within buildings in ducts or plenums or other spaces used for environmental air.
Space between the structural ceiling and the dropped ceiling or under a raised floor is typically considered plenum.
| Quantity: | |
|---|---|
Application：
Plenum Rated cable use within buildings in ducts or plenums or
other spaces used for environmental air.
Space between the structural ceiling and the dropped ceiling or
under a raised floor is typically considered plenum.
STANDARD COMPLIANCES：
All Category 6 Requirements as per ANSI/TIA, ISO/IEC,
and CENELEC EN Standards
TIA/EIA-568-C.2 Cat6
ISO/IEC 2nd Edition 11801 Class D
CENELEC EN 50173-1
IEC61156-6, CENELEC EN 50288-3-2 for patch cable
Flame Retardant is verified according to
IEC 60332-1-2, NEPA-262, NFPA-90A, UL-910
We Implemented ROSH compliance for the Requirement of
European Union Issued Directive 2002/95/EC
CONSTRUCTION & CHARACTERISTICS：
Conductor | Material/Size | Solid Bare Copper/23AWG |
Insulation | Material | FEP Flame Retardant |
Thickness | Nominal: 0.22 mm | |
Diameter | Nominal: 0.97 mm | |
Colors
| Blue/White-Blue Orange/White-Orange | |
Green/White-Green Brown/White/Brown | ||
Unaged Elongation | Min. 300% | |
Unaged Tensile Strength | Min. 1.683 Kgf/mm2 | |
Jacket
| Material | Fire Retardant PVC Low Smoke |
Thickness | Nominal: 0.58 mm | |
Diameter | Nominal: 6.4±0.2 mm | |
Color
| Assorted upon request | |
Unaged Elongation | Min. 125% | |
Unaged Tensile Strength | Min. 0.917 Kgf/mm2 | |
Aging @ 100℃ for 168Hrs | Min. elongation retention:75% |
Electrical Characteristics:
Impendance: | 100Ω±15% |
Max. Resistance Unbalance: | 2% |
Min. Propagation Velocity: | 0.65C |
Max. Mutual Capacitance: | 5.1nF/100m |
Max. Capacitance Unbalance: | 3400/3300 pF/Km |
Max. D.C Resistance | 9.38Ω/100m(23AWG) |
Max. D.C Loop Resistance: | 19.2Ω/100m |
Min. D.C Insulation Resistance: | 150MΩ/100Km |
Max. Propagation Delay Skew: | 30 ns/100m |
